Authentication

This page provides an overview of authentication in Kubernetes, with a focus on authentication to the Kubernetes API.

Users in Kubernetes

All Kubernetes clusters have two categories of users: ServiceAccounts managed by Kubernetes, and normal users.

In this regard, the core of Kubernetes does not have objects that represent normal user accounts. In other words, you can't make an API call to add a normal user to a plain Kubernetes cluster (if you extend Kubernetes with custom APIs, then that is a different situation and you could use your own custom API for user management).

Kubernetes is designed around an assumption that you have some mechanism to manage normal users, such as:

• you use an external user store that supports a mechanism such as OpenID Connect
• an administrator manually issues certificates and distributes these, along with private keys, to the right people
• you use an automatic process for issuing certificates to your users
• you have a file, or cluster component, with a list of usernames and password verifiers (and there is a way to manage that file)

If you have a way to manage users, external to Kubernetes, then you use that external means to add normal users.

In contrast, service accounts are machine identities and are managed by the Kubernetes API. They are either created automatically by the API server or manually through API calls; either way, each ServiceAccount exists within a specific Kubernetes Namespace. Every Kubernetes Pod runs as the ServiceAccount explicitly assigned to it. If no ServiceAccount is specified, the Pod automatically uses the default ServiceAccount in its namespace. Because the kubelet provides a mechanism to make it possible, the Pod can access a set of credentials that allow the Pod to act as that ServiceAccount.

Although ServiceAccounts are often used with Pods, you can also use them for other forms of machine identity or application identity that is associated with your cluster.

API requests are tied to either a normal user or a service account, or are treated as anonymous requests. This means every client inside or outside your cluster, from a human user typing kubectl on a workstation, to kubelets on nodes, to components of the control plane, must authenticate when making requests to the API server. If clients do not authenticate, they are treated as anonymous users.

Any kind of authenticated user can impersonate another user. This means that a ServiceAccount can impersonate a normal user (if authorized to do so), and a normal user can impersonate a ServiceAccount. The special user system:masters (a normal user identity that has special meaning to the authorization subsystem) can always impersonate any other user.

Authentication data

Kubernetes authenticates API requests using client certificates, bearer tokens, or an authenticating proxy through authentication plugins. As HTTP requests are made to the API server, plugins attempt to associate the following attributes with the client making the request:

Username

a string which identifies the end user. Example username values might be kube-admin or jane@example.com.

Unique ID

an optional opaque string value that identifies the end user and attempts to be more consistent and unique than username. For example: 9607a1a4-a742-4dda-9380-089d35a022b3.

Groups

a set of strings, each indicating the user's membership in a named logical collection of users. The character : (colon) is a Kubernetes convention for a separator, but you can use any other separator for your cluster. Example group names might be system:masters or devops-team.
The system:authenticated group is included in the list of groups for all authenticated users.

Extra fields

a map of strings to list of strings that holds additional information. The extra fields are typically information that authorizers would find useful.

Users can perform a self subject review to learn about their identity as recognised by the Kubernetes control plane.

Anonymous requests

When enabled, requests that are not rejected by other configured authentication methods are treated as anonymous requests, and given a username of system:anonymous and a group of system:unauthenticated.

For example, on a server with token authentication configured, and anonymous access enabled, a request providing an invalid bearer token would receive a 401 Unauthorized error. A request providing no bearer token would be treated as an anonymous request.

Anonymous access is enabled by default if an authorization mode other than AlwaysAllow is used; you can disable it by passing the --anonymous-auth=false command line option to the API server. The built-in ABAC and RBAC authorizers require explicit authorization of the system:anonymous user or the system:unauthenticated group; if you have legacy policy rules (from Kubernetes version 1.5 or earlier), those legacy rules that grant access to the * user or * group do not automatically allow access to anonymous users.

Anonymous authenticator configuration

The AuthenticationConfiguration can be used to configure the anonymous authenticator. If you set the anonymous field in the AuthenticationConfiguration file then you cannot set the --anonymous-auth command line option.

The main advantage of configuring anonymous authenticator using the authentication configuration file is that in addition to enabling and disabling anonymous authentication you can also configure which endpoints support anonymous authentication.

A sample authentication configuration file is below:

---
#
# CAUTION: this is an example configuration.
#          Do not use this as-is for your own cluster!
#
apiVersion: apiserver.config.k8s.io/v1beta1
kind: AuthenticationConfiguration
anonymous:
  enabled: true
  conditions:
  - path: /livez
  - path: /readyz
  - path: /healthz

In the configuration above, only the /livez, /readyz and /healthz endpoints are reachable by anonymous requests. Any other endpoints will not be reachable anonymously, even if your authorization configuration would allow it.

Authentication methods

You can enable multiple authentication methods at once. You should usually use at least two methods:

• service account tokens for ServiceAccounts
• at least one other method for (normal) user authentication

Available authentication methods include:

• X.509 client certificates
• Bootstrap tokens
• Service account tokens
• Static token file
• External integrations
  • OpenID Connect Tokens
  • Webhook token authentication
  • Authenticating reverse proxy

When multiple authenticator modules are enabled, the first module to successfully authenticate the request short-circuits evaluation. The API server does not guarantee the order authenticators run in.

X.509 client certificates

Any Kubernetes client that presents a valid client certificate signed by the cluster's client trust certificate authority (CA) is considered authenticated. In this configuration, Kubernetes determines the username from the commonName field in the subject of the certificate (for example, commonName=bob represents a user with username "bob"). From there, Kubernetes authorization mechanisms determine whether the user is allowed to perform a specific operation on a resource.

Client certificate authentication is enabled by passing the --client-ca-file=<SOMEFILE> option to API server. The referenced file must contain one or more certificate authorities to use to validate client certificates presented to the API server. If a client certificate is presented and verified, the common name of the subject is used as the user name for the request. Client certificates can also indicate a user's group memberships using the certificate's organization fields. To include multiple group memberships for a user, include multiple organization fields in the certificate.

For example, using the openssl command line tool to generate a certificate signing request:

openssl req -new -key jbeda.pem -out jbeda-csr.pem -subj "/CN=jbeda/O=app1/O=app2"

This would create a CSR for the username "jbeda", belonging to two groups, "app1" and "app2".

See Managing Certificates for how to generate a client cert.

Bootstrap tokens

To allow for streamlined bootstrapping for new clusters, Kubernetes includes a dynamically-managed Bearer token type called a Bootstrap Token. These tokens are stored as Secrets in the kube-system namespace, where they can be dynamically managed and created. Controller Manager contains a TokenCleaner controller that deletes bootstrap tokens as they expire.

The tokens are of the form [a-z0-9]{6}.[a-z0-9]{16}. The first component is a Token ID and the second component is the Token Secret. You specify the token in an HTTP header as follows:

Authorization: Bearer 781292.db7bc3a58fc5f07e

You must enable the Bootstrap Token Authenticator with the --enable-bootstrap-token-auth flag on the API Server. You must enable the TokenCleaner controller via the --controllers command line argument for kube-controller-manager. This is done with something like --controllers=*,tokencleaner. The kubeadm tool will do this for you if you are using it to bootstrap a cluster.

The authenticator authenticates as system:bootstrap:<Token ID>. It is included in the system:bootstrappers group. The naming and groups are intentionally limited to discourage users from using these tokens past bootstrapping. The user names and group can be used (and are used by kubeadm) to craft the appropriate authorization policies to support bootstrapping a cluster.

See Bootstrap Tokens for in depth documentation on the Bootstrap Token authenticator and controllers along with how to manage these tokens with kubeadm.

Service account tokens

The service account authentication plugin is automatically enabled and uses signed bearer tokens to verify requests. The plugin takes two optional command line arguments:

--service-account-key-file

File containing PEM-encoded x509 RSA or ECDSA private or public keys, used to verify ServiceAccount tokens. The specified file can contain multiple keys, and the argument can be specified multiple times with different files. If unspecified, Kubernetes uses the value of --tls-private-key-file.

--service-account-lookup

(boolean) If enabled, tokens which are deleted from the API will be revoked.

ServiceAccounts are usually created automatically by the API server and are associated with pods running in the cluster through the ServiceAccount Admission Controller. Bearer tokens are mounted into pods at well-known locations, and allow in-cluster clients to authenticate to the API server. ServiceAccounts may be explicitly associated with Pods using the serviceAccountName field within the spec of a Pod.

Here is a (partial) manifest for a Deployment that runs as a ServiceAccount named bob-the-bot:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
  namespace: default
spec:
  replicas: 3
  template:
    metadata:
    # ...
    spec:
      serviceAccountName: bob-the-bot
      containers:
      - name: nginx
        image: nginx:1.14.2

Service account bearer tokens are perfectly valid to use outside the cluster and can be used to create identities for long standing jobs that wish to talk to the Kubernetes API. To manually create a service account, use the kubectl create serviceaccount <NAME> subcommand. This creates a ServiceAccount in the current namespace.

kubectl create serviceaccount jenkins

serviceaccount/jenkins created

You can manually create an associated token:

kubectl create token jenkins

eyJhbGciOiJSUzI1NiIsImtp...

The created token is a signed JSON Web Token (JWT).

The signed JWT can be used as a bearer token to authenticate as the given service account. See above for how the token is included in a request. Normally these tokens are mounted into pods for in-cluster access to the API server, but can be used from outside the cluster as well.

ServiceAccounts authenticate with the username system:serviceaccount:<NAMESPACE>:<SERVICEACCOUNT>, and are assigned to the groups system:serviceaccounts and system:serviceaccounts:<NAMESPACE>.

Static token file

The API server reads bearer tokens from a file when given the --token-auth-file=SOMEFILE option on the command line. Tokens are valid indefinitely, and the token list cannot be changed without restarting the API server.

The token file is a CSV file with a minimum of 3 columns: token, username, user unique ID. The 4th column is a comma-separated list of groups that the user is a member of.

b87b5cee6a31,exampleuser,3d6602a9a7e4440091f1e63c70a1ca20,"administrators,examplegroup2,examplegroup3"

Putting a bearer token in a request

When using bearer token authentication from an http client, the API server expects an Authorization header with a value of Bearer <token>. The bearer token must be a character sequence that can be put in an HTTP header value using no more than the encoding and quoting facilities of HTTP. For example: if the bearer token is b87b5cee6a31 then it would appear in an HTTP header as shown below.

Authorization: Bearer b87b5cee6a31

External integrations

Kubernetes has native support for OpenID Connect (OIDC); see OpenID Connect tokens.

Integrations with other authentication protocols (for example: LDAP, SAML, Kerberos, alternate X.509 schemes) can be accomplished using an authenticating proxy or the authentication webhook.

OpenID Connect tokens

OpenID Connect is a flavor of OAuth2 supported by some OAuth2 providers, notably Microsoft Entra ID, Salesforce, and Google. The protocol's main extension of OAuth2 is an additional field returned with the access token called an ID Token. This token is a JSON Web Token (JWT) with well known fields, such as a user's email, signed by the server.

To identify the user, the authenticator uses the id_token (not the access_token) from the OAuth2 token response as a bearer token. See above for how the token is included in a request.

1. Log in to your identity provider

2. Your identity provider will provide you with an access_token, id_token and a refresh_token

3. When using kubectl, use your id_token with the --token command line argument or add it directly to your kubeconfig

4. kubectl sends your id_token in a header called Authorization to the API server

5. The API server will make sure the JWT signature is valid

6. Check to make sure the id_token hasn't expired

   Perform claim and/or user validation if CEL expressions are configured with AuthenticationConfiguration.

7. Make sure the user is authorized

8. Once authorized the API server returns a response to kubectl

9. kubectl provides feedback to the user

Since all of the data needed to validate who you are is in the id_token, Kubernetes doesn't need to "phone home" to the identity provider. In a model where every request is stateless this provides a very scalable solution for authentication. It does offer a few challenges:

1. Kubernetes has no "web interface" to trigger the authentication process. There is no browser or interface to collect credentials which is why you need to authenticate to your identity provider first.
2. The id_token can't be revoked, it's like a certificate so it should be short-lived (only a few minutes) so it can be very annoying to have to get a new token every few minutes.
3. To authenticate to the Kubernetes dashboard, you must use the kubectl proxy command or a reverse proxy that injects the id_token.

Configuring the API Server

Using command line arguments

To enable the plugin, configure the following command line arguments for the API server:

Authentication configuration from a file

JWT Authenticator is an authenticator to authenticate Kubernetes users using JWT compliant tokens. The authenticator will attempt to parse a raw ID token, verify it's been signed by the configured issuer. The public key to verify the signature is discovered from the issuer's public endpoint using OIDC discovery.

The minimum valid JWT payload must contain the following claims:

{
  "iss": "https://example.com",   // must match the issuer.url
  "aud": ["my-app"],              // at least one of the entries in issuer.audiences must match the "aud" claim in presented JWTs.
  "exp": 1234567890,              // token expiration as Unix time (the number of seconds elapsed since January 1, 1970 UTC)
  "<username-claim>": "user"      // this is the username claim configured in the claimMappings.username.claim or claimMappings.username.expression
}

The configuration file approach allows you to configure multiple JWT authenticators, each with a unique issuer.url and issuer.discoveryURL. The configuration file even allows you to specify CEL expressions to map claims to user attributes, and to validate claims and user information. The API server also automatically reloads the authenticators when the configuration file is modified. You can use apiserver_authentication_config_controller_automatic_reload_last_timestamp_seconds metric to monitor the last time the configuration was reloaded by the API server.

You must specify the path to the authentication configuration using the --authentication-config command line argument to the API server. If you want to use command line arguments instead of the configuration file, those will continue to work as-is. To access the new capabilities like configuring multiple authenticators, setting multiple audiences for an issuer, switch to using the configuration file.

For Kubernetes v1.32, the structured authentication configuration file format is beta-level, and the mechanism for using that configuration is also beta. Provided you didn't specifically disable the StructuredAuthenticationConfiguration feature gate for your cluster, you can turn on structured authentication by specifying the --authentication-config command line argument to the kube-apiserver. An example of the structured authentication configuration file is shown below.

---
#
# CAUTION: this is an example configuration.
#          Do not use this for your own cluster!
#
apiVersion: apiserver.config.k8s.io/v1beta1
kind: AuthenticationConfiguration
# list of authenticators to authenticate Kubernetes users using JWT compliant tokens.
# the maximum number of allowed authenticators is 64.
jwt:
- issuer:
    # url must be unique across all authenticators.
    # url must not conflict with issuer configured in --service-account-issuer.
    url: https://example.com # Same as --oidc-issuer-url.
    # discoveryURL, if specified, overrides the URL used to fetch discovery
    # information instead of using "{url}/.well-known/openid-configuration".
    # The exact value specified is used, so "/.well-known/openid-configuration"
    # must be included in discoveryURL if needed.
    #
    # The "issuer" field in the fetched discovery information must match the "issuer.url" field
    # in the AuthenticationConfiguration and will be used to validate the "iss" claim in the presented JWT.
    # This is for scenarios where the well-known and jwks endpoints are hosted at a different
    # location than the issuer (such as locally in the cluster).
    # discoveryURL must be different from url if specified and must be unique across all authenticators.
    discoveryURL: https://discovery.example.com/.well-known/openid-configuration
    # PEM encoded CA certificates used to validate the connection when fetching
    # discovery information. If not set, the system verifier will be used.
    # Same value as the content of the file referenced by the --oidc-ca-file command line argument.
    certificateAuthority: <PEM encoded CA certificates>
    # audiences is the set of acceptable audiences the JWT must be issued to.
    # At least one of the entries must match the "aud" claim in presented JWTs.
    audiences:
    - my-app # Same as --oidc-client-id.
    - my-other-app
    # this is required to be set to "MatchAny" when multiple audiences are specified.
    audienceMatchPolicy: MatchAny
  # rules applied to validate token claims to authenticate users.
  claimValidationRules:
    # Same as --oidc-required-claim key=value.
  - claim: hd
    requiredValue: example.com
    # Instead of claim and requiredValue, you can use expression to validate the claim.
    # expression is a CEL expression that evaluates to a boolean.
    # all the expressions must evaluate to true for validation to succeed.
  - expression: 'claims.hd == "example.com"'
    # Message customizes the error message seen in the API server logs when the validation fails.
    message: the hd claim must be set to example.com
  - expression: 'claims.exp - claims.nbf <= 86400'
    message: total token lifetime must not exceed 24 hours
  claimMappings:
    # username represents an option for the username attribute.
    # This is the only required attribute.
    username:
      # Same as --oidc-username-claim. Mutually exclusive with username.expression.
      claim: "sub"
      # Same as --oidc-username-prefix. Mutually exclusive with username.expression.
      # if username.claim is set, username.prefix is required.
      # Explicitly set it to "" if no prefix is desired.
      prefix: ""
      # Mutually exclusive with username.claim and username.prefix.
      # expression is a CEL expression that evaluates to a string.
      #
      # 1.  If username.expression uses 'claims.email', then 'claims.email_verified' must be used in
      #     username.expression or extra[*].valueExpression or claimValidationRules[*].expression.
      #     An example claim validation rule expression that matches the validation automatically
      #     applied when username.claim is set to 'email' is 'claims.?email_verified.orValue(true) == true'.
      #     By explicitly comparing the value to true, we let type-checking see the result will be a boolean, and
      #     to make sure a non-boolean email_verified claim will be caught at runtime.
      # 2.  If the username asserted based on username.expression is the empty string, the authentication
      #     request will fail.
      expression: 'claims.username + ":external-user"'
    # groups represents an option for the groups attribute.
    groups:
      # Same as --oidc-groups-claim. Mutually exclusive with groups.expression.
      claim: "sub"
      # Same as --oidc-groups-prefix. Mutually exclusive with groups.expression.
      # if groups.claim is set, groups.prefix is required.
      # Explicitly set it to "" if no prefix is desired.
      prefix: ""
      # Mutually exclusive with groups.claim and groups.prefix.
      # expression is a CEL expression that evaluates to a string or a list of strings.
      expression: 'claims.roles.split(",")'
    # uid represents an option for the uid attribute.
    uid:
      # Mutually exclusive with uid.expression.
      claim: 'sub'
      # Mutually exclusive with uid.claim
      # expression is a CEL expression that evaluates to a string.
      expression: 'claims.sub'
    # extra attributes to be added to the UserInfo object. Keys must be domain-prefix path and must be unique.
    extra:
      # key is a string to use as the extra attribute key.
      # key must be a domain-prefix path (e.g. example.org/foo). All characters before the first "/" must be a valid
      # subdomain as defined by RFC 1123. All characters trailing the first "/" must
      # be valid HTTP Path characters as defined by RFC 3986.
      # k8s.io, kubernetes.io and their subdomains are reserved for Kubernetes use and cannot be used.
      # key must be lowercase and unique across all extra attributes.
    - key: 'example.com/tenant'
      # valueExpression is a CEL expression that evaluates to a string or a list of strings.
      valueExpression: 'claims.tenant'
  # validation rules applied to the final user object.
  userValidationRules:
    # expression is a CEL expression that evaluates to a boolean.
    # all the expressions must evaluate to true for the user to be valid.
  - expression: "!user.username.startsWith('system:')"
    # Message customizes the error message seen in the API server logs when the validation fails.
    message: 'username cannot used reserved system: prefix'
  - expression: "user.groups.all(group, !group.startsWith('system:'))"
    message: 'groups cannot used reserved system: prefix'

• Claim validation rule expression

  jwt.claimValidationRules[i].expression represents the expression which will be evaluated by CEL. CEL expressions have access to the contents of the token payload, organized into claims CEL variable. claims is a map of claim names (as strings) to claim values (of any type).

• User validation rule expression

  jwt.userValidationRules[i].expression represents the expression which will be evaluated by CEL. CEL expressions have access to the contents of userInfo, organized into user CEL variable. Refer to the UserInfo API documentation for the schema of user.

• Claim mapping expression

  jwt.claimMappings.username.expression, jwt.claimMappings.groups.expression, jwt.claimMappings.uid.expression jwt.claimMappings.extra[i].valueExpression represents the expression which will be evaluated by CEL. CEL expressions have access to the contents of the token payload, organized into claims CEL variable. claims is a map of claim names (as strings) to claim values (of any type).

  To learn more, see the Documentation on CEL

  Here are examples of the AuthenticationConfiguration with different token payloads.

  • Valid token
  • Fails claim validation
  • Fails user validation

  apiVersion: apiserver.config.k8s.io/v1beta1
  kind: AuthenticationConfiguration
  jwt:
  - issuer:
      url: https://example.com
      audiences:
      - my-app
    claimMappings:
      username:
        expression: 'claims.username + ":external-user"'
      groups:
        expression: 'claims.roles.split(",")'
      uid:
        expression: 'claims.sub'
      extra:
      - key: 'example.com/tenant'
        valueExpression: 'claims.tenant'
    userValidationRules:
    - expression: "!user.username.startsWith('system:')" # the expression will evaluate to true, so validation will succeed.
      message: 'username cannot used reserved system: prefix'


  TOKEN=eyJhbGciOiJSUzI1NiIsImtpZCI6ImY3dF9tOEROWmFTQk1oWGw5QXZTWGhBUC04Y0JmZ0JVbFVpTG5oQkgxdXMiLCJ0eXAiOiJKV1QifQ.eyJhdWQiOiJrdWJlcm5ldGVzIiwiZXhwIjoxNzAzMjMyOTQ5LCJpYXQiOjE3MDExMDcyMzMsImlzcyI6Imh0dHBzOi8vZXhhbXBsZS5jb20iLCJqdGkiOiI3YzMzNzk0MjgwN2U3M2NhYTJjMzBjODY4YWMwY2U5MTBiY2UwMmRkY2JmZWJlOGMyM2I4YjVmMjdhZDYyODczIiwibmJmIjoxNzAxMTA3MjMzLCJyb2xlcyI6InVzZXIsYWRtaW4iLCJzdWIiOiJhdXRoIiwidGVuYW50IjoiNzJmOTg4YmYtODZmMS00MWFmLTkxYWItMmQ3Y2QwMTFkYjRhIiwidXNlcm5hbWUiOiJmb28ifQ.TBWF2RkQHm4QQz85AYPcwLxSk-VLvQW-mNDHx7SEOSv9LVwcPYPuPajJpuQn9C_gKq1R94QKSQ5F6UgHMILz8OfmPKmX_00wpwwNVGeevJ79ieX2V-__W56iNR5gJ-i9nn6FYk5pwfVREB0l4HSlpTOmu80gbPWAXY5hLW0ZtcE1JTEEmefORHV2ge8e3jp1xGafNy6LdJWabYuKiw8d7Qga__HxtKB-t0kRMNzLRS7rka_SfQg0dSYektuxhLbiDkqhmRffGlQKXGVzUsuvFw7IGM5ZWnZgEMDzCI357obHeM3tRqpn5WRjtB8oM7JgnCymaJi-P3iCd88iu1xnzA


  where the token payload is:

    {
      "aud": "kubernetes",
      "exp": 1703232949,
      "iat": 1701107233,
      "iss": "https://example.com",
      "jti": "7c337942807e73caa2c30c868ac0ce910bce02ddcbfebe8c23b8b5f27ad62873",
      "nbf": 1701107233,
      "roles": "user,admin",
      "sub": "auth",
      "tenant": "72f988bf-86f1-41af-91ab-2d7cd011db4a",
      "username": "foo"
    }


  The token with the above AuthenticationConfiguration will produce the following UserInfo object and successfully authenticate the user.

  {
      "username": "foo:external-user",
      "uid": "auth",
      "groups": [
          "user",
          "admin"
      ],
      "extra": {
          "example.com/tenant": "72f988bf-86f1-41af-91ab-2d7cd011db4a"
      }
  }


  apiVersion: apiserver.config.k8s.io/v1beta1
  kind: AuthenticationConfiguration
  jwt:
  - issuer:
      url: https://example.com
      audiences:
      - my-app
    claimValidationRules:
    - expression: 'claims.hd == "example.com"' # the token below does not have this claim, so validation will fail.
      message: the hd claim must be set to example.com
    claimMappings:
      username:
        expression: 'claims.username + ":external-user"'
      groups:
        expression: 'claims.roles.split(",")'
      uid:
        expression: 'claims.sub'
      extra:
      - key: 'example.com/tenant'
        valueExpression: 'claims.tenant'
    userValidationRules:
    - expression: "!user.username.startsWith('system:')" # the expression will evaluate to true, so validation will succeed.
      message: 'username cannot used reserved system: prefix'


  TOKEN=eyJhbGciOiJSUzI1NiIsImtpZCI6ImY3dF9tOEROWmFTQk1oWGw5QXZTWGhBUC04Y0JmZ0JVbFVpTG5oQkgxdXMiLCJ0eXAiOiJKV1QifQ.eyJhdWQiOiJrdWJlcm5ldGVzIiwiZXhwIjoxNzAzMjMyOTQ5LCJpYXQiOjE3MDExMDcyMzMsImlzcyI6Imh0dHBzOi8vZXhhbXBsZS5jb20iLCJqdGkiOiI3YzMzNzk0MjgwN2U3M2NhYTJjMzBjODY4YWMwY2U5MTBiY2UwMmRkY2JmZWJlOGMyM2I4YjVmMjdhZDYyODczIiwibmJmIjoxNzAxMTA3MjMzLCJyb2xlcyI6InVzZXIsYWRtaW4iLCJzdWIiOiJhdXRoIiwidGVuYW50IjoiNzJmOTg4YmYtODZmMS00MWFmLTkxYWItMmQ3Y2QwMTFkYjRhIiwidXNlcm5hbWUiOiJmb28ifQ.TBWF2RkQHm4QQz85AYPcwLxSk-VLvQW-mNDHx7SEOSv9LVwcPYPuPajJpuQn9C_gKq1R94QKSQ5F6UgHMILz8OfmPKmX_00wpwwNVGeevJ79ieX2V-__W56iNR5gJ-i9nn6FYk5pwfVREB0l4HSlpTOmu80gbPWAXY5hLW0ZtcE1JTEEmefORHV2ge8e3jp1xGafNy6LdJWabYuKiw8d7Qga__HxtKB-t0kRMNzLRS7rka_SfQg0dSYektuxhLbiDkqhmRffGlQKXGVzUsuvFw7IGM5ZWnZgEMDzCI357obHeM3tRqpn5WRjtB8oM7JgnCymaJi-P3iCd88iu1xnzA


  where the token payload is:

    {
      "aud": "kubernetes",
      "exp": 1703232949,
      "iat": 1701107233,
      "iss": "https://example.com",
      "jti": "7c337942807e73caa2c30c868ac0ce910bce02ddcbfebe8c23b8b5f27ad62873",
      "nbf": 1701107233,
      "roles": "user,admin",
      "sub": "auth",
      "tenant": "72f988bf-86f1-41af-91ab-2d7cd011db4a",
      "username": "foo"
    }


  The token with the above AuthenticationConfiguration will fail to authenticate because the hd claim is not set to example.com. The API server will return 401 Unauthorized error.

  apiVersion: apiserver.config.k8s.io/v1beta1
  kind: AuthenticationConfiguration
  jwt:
  - issuer:
      url: https://example.com
      audiences:
      - my-app
    claimValidationRules:
    - expression: 'claims.hd == "example.com"'
      message: the hd claim must be set to example.com
    claimMappings:
      username:
        expression: '"system:" + claims.username' # this will prefix the username with "system:" and will fail user validation.
      groups:
        expression: 'claims.roles.split(",")'
      uid:
        expression: 'claims.sub'
      extra:
      - key: 'example.com/tenant'
        valueExpression: 'claims.tenant'
    userValidationRules:
    - expression: "!user.username.startsWith('system:')" # the username will be system:foo and expression will evaluate to false, so validation will fail.
      message: 'username cannot used reserved system: prefix'


  TOKEN=eyJhbGciOiJSUzI1NiIsImtpZCI6ImY3dF9tOEROWmFTQk1oWGw5QXZTWGhBUC04Y0JmZ0JVbFVpTG5oQkgxdXMiLCJ0eXAiOiJKV1QifQ.eyJhdWQiOiJrdWJlcm5ldGVzIiwiZXhwIjoxNzAzMjMyOTQ5LCJoZCI6ImV4YW1wbGUuY29tIiwiaWF0IjoxNzAxMTEzMTAxLCJpc3MiOiJodHRwczovL2V4YW1wbGUuY29tIiwianRpIjoiYjViMDY1MjM3MmNkMjBlMzQ1YjZmZGZmY2RjMjE4MWY0YWZkNmYyNTlhYWI0YjdlMzU4ODEyMzdkMjkyMjBiYyIsIm5iZiI6MTcwMTExMzEwMSwicm9sZXMiOiJ1c2VyLGFkbWluIiwic3ViIjoiYXV0aCIsInRlbmFudCI6IjcyZjk4OGJmLTg2ZjEtNDFhZi05MWFiLTJkN2NkMDExZGI0YSIsInVzZXJuYW1lIjoiZm9vIn0.FgPJBYLobo9jnbHreooBlvpgEcSPWnKfX6dc0IvdlRB-F0dCcgy91oCJeK_aBk-8zH5AKUXoFTlInfLCkPivMOJqMECA1YTrMUwt_IVqwb116AqihfByUYIIqzMjvUbthtbpIeHQm2fF0HbrUqa_Q0uaYwgy8mD807h7sBcUMjNd215ff_nFIHss-9zegH8GI1d9fiBf-g6zjkR1j987EP748khpQh9IxPjMJbSgG_uH5x80YFuqgEWwq-aYJPQxXX6FatP96a2EAn7wfPpGlPRt0HcBOvq5pCnudgCgfVgiOJiLr_7robQu4T1bis0W75VPEvwWtgFcLnvcQx0JWg


  where the token payload is:

    {
      "aud": "kubernetes",
      "exp": 1703232949,
      "hd": "example.com",
      "iat": 1701113101,
      "iss": "https://example.com",
      "jti": "b5b0652372cd20e345b6fdffcdc2181f4afd6f259aab4b7e35881237d29220bc",
      "nbf": 1701113101,
      "roles": "user,admin",
      "sub": "auth",
      "tenant": "72f988bf-86f1-41af-91ab-2d7cd011db4a",
      "username": "foo"
    }


  The token with the above AuthenticationConfiguration will produce the following UserInfo object:

  {
      "username": "system:foo",
      "uid": "auth",
      "groups": [
          "user",
          "admin"
      ],
      "extra": {
          "example.com/tenant": "72f988bf-86f1-41af-91ab-2d7cd011db4a"
      }
  }


  which will fail user validation because the username starts with system:. The API server will return 401 Unauthorized error.

Limitations

1. Distributed claims do not work via CEL expressions.
2. Egress selector configuration is not supported for calls to issuer.url and issuer.discoveryURL.

Kubernetes does not provide an OpenID Connect Identity Provider. You can use an existing public OpenID Connect Identity Provider (such as Google, or others). Or, you can run your own Identity Provider, such as dex, Keycloak, CloudFoundry UAA, or Tremolo Security's OpenUnison.

For an identity provider to work with Kubernetes it must:

1. Support OpenID connect discovery

   The public key to verify the signature is discovered from the issuer's public endpoint using OIDC discovery. If you're using the authentication configuration file, the identity provider doesn't need to publicly expose the discovery endpoint. You can host the discovery endpoint at a different location than the issuer (such as locally in the cluster) and specify the issuer.discoveryURL in the configuration file.

2. Run in TLS with non-obsolete ciphers

3. Have a CA signed certificate (even if the CA is not a commercial CA or is self signed)

A note about requirement #3 above, requiring a CA signed certificate. If you deploy your own identity provider (as opposed to one of the cloud providers like Google or Microsoft) you MUST have your identity provider's web server certificate signed by a certificate with the CA flag set to TRUE, even if it is self signed. This is due to GoLang's TLS client implementation being very strict to the standards around certificate validation. If you don't have a CA handy, you can use the gencert script from the Dex team to create a simple CA and a signed certificate and key pair. Or you can use this similar script that generates SHA256 certs with a longer life and larger key size.

Refer to setup instructions for specific systems:

• UAA
• Dex
• OpenUnison

Using kubectl

Option 1 - OIDC authenticator

The first option is to use the kubectl oidc authenticator, which sets the id_token as a bearer token for all requests and refreshes the token once it expires. After you've logged into your provider, use kubectl to add your id_token, refresh_token, client_id, and client_secret to configure the plugin.

Providers that don't return an id_token as part of their refresh token response aren't supported by this plugin and should use Option 2 (specifying --token).

kubectl config set-credentials USER_NAME \
   --auth-provider=oidc \
   --auth-provider-arg=idp-issuer-url=( issuer url ) \
   --auth-provider-arg=client-id=( your client id ) \
   --auth-provider-arg=client-secret=( your client secret ) \
   --auth-provider-arg=refresh-token=( your refresh token ) \
   --auth-provider-arg=idp-certificate-authority=( path to your ca certificate ) \
   --auth-provider-arg=id-token=( your id_token )

As an example, running the below command after authenticating to your identity provider:

kubectl config set-credentials mmosley  \
        --auth-provider=oidc  \
        --auth-provider-arg=idp-issuer-url=https://oidcidp.tremolo.lan:8443/auth/idp/OidcIdP  \
        --auth-provider-arg=client-id=kubernetes  \
        --auth-provider-arg=client-secret=1db158f6-177d-4d9c-8a8b-d36869918ec5  \
        --auth-provider-arg=refresh-token=q1bKLFOyUiosTfawzA93TzZIDzH2TNa2SMm0zEiPKTUwME6BkEo6Sql5yUWVBSWpKUGphaWpxSVAfekBOZbBhaEW+VlFUeVRGcluyVF5JT4+haZmPsluFoFu5XkpXk5BXqHega4GAXlF+ma+vmYpFcHe5eZR+slBFpZKtQA= \
        --auth-provider-arg=idp-certificate-authority=/root/ca.pem \
        --auth-provider-arg=id-token=eyJraWQiOiJDTj1vaWRjaWRwLnRyZW1vbG8ubGFuLCBPVT1EZW1vLCBPPVRybWVvbG8gU2VjdXJpdHksIEw9QXJsaW5ndG9uLCBTVD1WaXJnaW5pYSwgQz1VUy1DTj1rdWJlLWNhLTEyMDIxNDc5MjEwMzYwNzMyMTUyIiwiYWxnIjoiUlMyNTYifQ.eyJpc3MiOiJodHRwczovL29pZGNpZHAudHJlbW9sby5sYW46ODQ0My9hdXRoL2lkcC9PaWRjSWRQIiwiYXVkIjoia3ViZXJuZXRlcyIsImV4cCI6MTQ4MzU0OTUxMSwianRpIjoiMm96US15TXdFcHV4WDlHZUhQdy1hZyIsImlhdCI6MTQ4MzU0OTQ1MSwibmJmIjoxNDgzNTQ5MzMxLCJzdWIiOiI0YWViMzdiYS1iNjQ1LTQ4ZmQtYWIzMC0xYTAxZWU0MWUyMTgifQ.w6p4J_6qQ1HzTG9nrEOrubxIMb9K5hzcMPxc9IxPx2K4xO9l-oFiUw93daH3m5pluP6K7eOE6txBuRVfEcpJSwlelsOsW8gb8VJcnzMS9EnZpeA0tW_p-mnkFc3VcfyXuhe5R3G7aa5d8uHv70yJ9Y3-UhjiN9EhpMdfPAoEB9fYKKkJRzF7utTTIPGrSaSU6d2pcpfYKaxIwePzEkT4DfcQthoZdy9ucNvvLoi1DIC-UocFD8HLs8LYKEqSxQvOcvnThbObJ9af71EwmuE21fO5KzMW20KtAeget1gnldOosPtz1G5EwvaQ401-RPQzPGMVBld0_zMCAwZttJ4knw

Which would produce the below configuration:

users:
- name: mmosley
  user:
    auth-provider:
      config:
        client-id: kubernetes
        client-secret: 1db158f6-177d-4d9c-8a8b-d36869918ec5
        id-token: eyJraWQiOiJDTj1vaWRjaWRwLnRyZW1vbG8ubGFuLCBPVT1EZW1vLCBPPVRybWVvbG8gU2VjdXJpdHksIEw9QXJsaW5ndG9uLCBTVD1WaXJnaW5pYSwgQz1VUy1DTj1rdWJlLWNhLTEyMDIxNDc5MjEwMzYwNzMyMTUyIiwiYWxnIjoiUlMyNTYifQ.eyJpc3MiOiJodHRwczovL29pZGNpZHAudHJlbW9sby5sYW46ODQ0My9hdXRoL2lkcC9PaWRjSWRQIiwiYXVkIjoia3ViZXJuZXRlcyIsImV4cCI6MTQ4MzU0OTUxMSwianRpIjoiMm96US15TXdFcHV4WDlHZUhQdy1hZyIsImlhdCI6MTQ4MzU0OTQ1MSwibmJmIjoxNDgzNTQ5MzMxLCJzdWIiOiI0YWViMzdiYS1iNjQ1LTQ4ZmQtYWIzMC0xYTAxZWU0MWUyMTgifQ.w6p4J_6qQ1HzTG9nrEOrubxIMb9K5hzcMPxc9IxPx2K4xO9l-oFiUw93daH3m5pluP6K7eOE6txBuRVfEcpJSwlelsOsW8gb8VJcnzMS9EnZpeA0tW_p-mnkFc3VcfyXuhe5R3G7aa5d8uHv70yJ9Y3-UhjiN9EhpMdfPAoEB9fYKKkJRzF7utTTIPGrSaSU6d2pcpfYKaxIwePzEkT4DfcQthoZdy9ucNvvLoi1DIC-UocFD8HLs8LYKEqSxQvOcvnThbObJ9af71EwmuE21fO5KzMW20KtAeget1gnldOosPtz1G5EwvaQ401-RPQzPGMVBld0_zMCAwZttJ4knw
        idp-certificate-authority: /root/ca.pem
        idp-issuer-url: https://oidcidp.tremolo.lan:8443/auth/idp/OidcIdP
        refresh-token: q1bKLFOyUiosTfawzA93TzZIDzH2TNa2SMm0zEiPKTUwME6BkEo6Sql5yUWVBSWpKUGphaWpxSVAfekBOZbBhaEW+VlFUeVRGcluyVF5JT4+haZmPsluFoFu5XkpXk5BXq
      name: oidc

Once your id_token expires, kubectl will attempt to refresh your id_token using your refresh_token and client_secret storing the new values for the refresh_token and id_token in your .kube/config.

Option 2 - Use the --token command line argument

The kubectl command lets you pass in a token using the --token command line argument. Copy and paste the id_token into this option:

kubectl --token=eyJhbGciOiJSUzI1NiJ9.eyJpc3MiOiJodHRwczovL21sYi50cmVtb2xvLmxhbjo4MDQzL2F1dGgvaWRwL29pZGMiLCJhdWQiOiJrdWJlcm5ldGVzIiwiZXhwIjoxNDc0NTk2NjY5LCJqdGkiOiI2RDUzNXoxUEpFNjJOR3QxaWVyYm9RIiwiaWF0IjoxNDc0NTk2MzY5LCJuYmYiOjE0NzQ1OTYyNDksInN1YiI6Im13aW5kdSIsInVzZXJfcm9sZSI6WyJ1c2VycyIsIm5ldy1uYW1lc3BhY2Utdmlld2VyIl0sImVtYWlsIjoibXdpbmR1QG5vbW9yZWplZGkuY29tIn0.f2As579n9VNoaKzoF-dOQGmXkFKf1FMyNV0-va_B63jn-_n9LGSCca_6IVMP8pO-Zb4KvRqGyTP0r3HkHxYy5c81AnIh8ijarruczl-TK_yF5akjSTHFZD-0gRzlevBDiH8Q79NAr-ky0P4iIXS8lY9Vnjch5MF74Zx0c3alKJHJUnnpjIACByfF2SCaYzbWFMUNat-K1PaUk5-ujMBG7yYnr95xD-63n8CO8teGUAAEMx6zRjzfhnhbzX-ajwZLGwGUBT4WqjMs70-6a7_8gZmLZb2az1cZynkFRj2BaCkVT3A2RrjeEwZEtGXlMqKJ1_I2ulrOVsYx01_yD35-rw get nodes

Webhook token authentication

Kubernetes webhook authentication is a mechanism to make an HTTP callout for verifying bearer tokens.

In terms of how you configure the API server:

• --authentication-token-webhook-config-file a configuration file describing how to access the remote webhook service.
• --authentication-token-webhook-cache-ttl how long to cache authentication decisions. Defaults to two minutes.
• --authentication-token-webhook-version determines whether to use authentication.k8s.io/v1beta1 or authentication.k8s.io/v1 TokenReview objects to send/receive information from the webhook. Defaults to v1beta1.

The configuration file uses the kubeconfig file format. Within the file, clusters refers to the remote service and users refers to the API server webhook. An example would be:

# Kubernetes API version
apiVersion: v1
# kind of the API object
kind: Config
# clusters refers to the remote service.
clusters:
  - name: name-of-remote-authn-service
    cluster:
      certificate-authority: /path/to/ca.pem         # CA for verifying the remote service.
      server: https://authn.example.com/authenticate # URL of remote service to query. 'https' recommended for production.

# users refers to the API server's webhook configuration.
users:
  - name: name-of-api-server
    user:
      client-certificate: /path/to/cert.pem # cert for the webhook plugin to use
      client-key: /path/to/key.pem          # key matching the cert

# kubeconfig files require a context. Provide one for the API server.
current-context: webhook
contexts:
- context:
    cluster: name-of-remote-authn-service
    user: name-of-api-server
  name: webhook

When a client attempts to authenticate with the API server using a bearer token as discussed above, the authentication webhook POSTs a JSON-serialized TokenReview object containing the token to the remote service.

Note that webhook API objects are subject to the same versioning compatibility rules as other Kubernetes API objects. Implementers should check the apiVersion field of the request to ensure correct deserialization, and must respond with a TokenReview object of the same version as the request.

• authentication.k8s.io/v1
• authentication.k8s.io/v1beta1

{
  "apiVersion": "authentication.k8s.io/v1",
  "kind": "TokenReview",
  "spec": {
    # Opaque bearer token sent to the API server
    "token": "014fbff9a07c...",

    # Optional list of the audience identifiers for the server the token was presented to.
    # Audience-aware token authenticators (for example, OIDC token authenticators)
    # should verify the token was intended for at least one of the audiences in this list,
    # and return the intersection of this list and the valid audiences for the token in the response status.
    # This ensures the token is valid to authenticate to the server it was presented to.
    # If no audiences are provided, the token should be validated to authenticate to the Kubernetes API server.
    "audiences": ["https://myserver.example.com", "https://myserver.internal.example.com"]
  }
}

{
  "apiVersion": "authentication.k8s.io/v1beta1",
  "kind": "TokenReview",
  "spec": {
    # Opaque bearer token sent to the API server
    "token": "014fbff9a07c...",

    # Optional list of the audience identifiers for the server the token was presented to.
    # Audience-aware token authenticators (for example, OIDC token authenticators)
    # should verify the token was intended for at least one of the audiences in this list,
    # and return the intersection of this list and the valid audiences for the token in the response status.
    # This ensures the token is valid to authenticate to the server it was presented to.
    # If no audiences are provided, the token should be validated to authenticate to the Kubernetes API server.
    "audiences": ["https://myserver.example.com", "https://myserver.internal.example.com"]
  }
}

The remote service is expected to fill the status field of the request to indicate the success of the login. The response body's spec field is ignored and may be omitted. The remote service must return a response using the same TokenReview API version that it received. A successful validation of the bearer token would return:

• authentication.k8s.io/v1
• authentication.k8s.io/v1beta1

{
  "apiVersion": "authentication.k8s.io/v1",
  "kind": "TokenReview",
  "status": {
    "authenticated": true,
    "user": {
      # Required
      "username": "janedoe@example.com",
      # Optional
      "uid": "42",
      # Optional group memberships
      "groups": ["developers", "qa"],
      # Optional additional information provided by the authenticator.
      # This should not contain confidential data, as it can be recorded in logs
      # or API objects, and is made available to admission webhooks.
      "extra": {
        "extrafield1": [
          "extravalue1",
          "extravalue2"
        ]
      }
    },
    # Optional list audience-aware token authenticators can return,
    # containing the audiences from the `spec.audiences` list for which the provided token was valid.
    # If this is omitted, the token is considered to be valid to authenticate to the Kubernetes API server.
    "audiences": ["https://myserver.example.com"]
  }
}

{
  "apiVersion": "authentication.k8s.io/v1beta1",
  "kind": "TokenReview",
  "status": {
    "authenticated": true,
    "user": {
      # Required
      "username": "janedoe@example.com",
      # Optional
      "uid": "42",
      # Optional group memberships
      "groups": ["developers", "qa"],
      # Optional additional information provided by the authenticator.
      # This should not contain confidential data, as it can be recorded in logs
      # or API objects, and is made available to admission webhooks.
      "extra": {
        "extrafield1": [
          "extravalue1",
          "extravalue2"
        ]
      }
    },
    # Optional list audience-aware token authenticators can return,
    # containing the audiences from the `spec.audiences` list for which the provided token was valid.
    # If this is omitted, the token is considered to be valid to authenticate to the Kubernetes API server.
    "audiences": ["https://myserver.example.com"]
  }
}

An unsuccessful request would return:

• authentication.k8s.io/v1
• authentication.k8s.io/v1beta1

{
  "apiVersion": "authentication.k8s.io/v1",
  "kind": "TokenReview",
  "status": {
    "authenticated": false,
    # Optionally include details about why authentication failed.
    # If no error is provided, the API will return a generic Unauthorized message.
    # The error field is ignored when authenticated=true.
    "error": "Credentials are expired"
  }
}

{
  "apiVersion": "authentication.k8s.io/v1beta1",
  "kind": "TokenReview",
  "status": {
    "authenticated": false,
    # Optionally include details about why authentication failed.
    # If no error is provided, the API will return a generic Unauthorized message.
    # The error field is ignored when authenticated=true.
    "error": "Credentials are expired"
  }
}

Authenticating reverse proxy

The API server can be configured to identify users from request header values, such as X-Remote-User. It is designed for use in combination with an authenticating proxy that sets these headers.

The command line arguments to configure this mode are:

--requestheader-client-ca-file

Required. Path to a PEM-encoded certificate bundle.
A valid client certificate must be presented and validated against the certificate authorities in the specified file before the request headers are checked for user names.

--requestheader-allowed-names

Optional. Comma-separated list of Common Name values (CNs).
If set, a valid client certificate with a CN in the specified list must be presented before the request headers are checked for user names. If empty, any CN is allowed.

--requestheader-username-headers

Required; case-insensitive. Header names to check, in order, for the user identity.
The first header containing a value is used as the username.

--requestheader-group-headers

Optional; case-insensitive. Header names to check, in order, for the user's groups.
X-Remote-Group is suggested. All values in all specified headers are used as group names.

--requestheader-extra-headers-prefix

Optional; case-insensitive. Header prefixes to look for to determine extra information about the user.
X-Remote-Extra- is suggested. Extra data is typically used by the configured authorization plugin(s). Any headers beginning with any of the specified prefixes have the prefix removed. The remainder of the header name is lowercased and percent-decoded and becomes the extra key, and the header value is the extra value.

For example, with this configuration:

--requestheader-username-headers=X-Remote-User
--requestheader-group-headers=X-Remote-Group
--requestheader-extra-headers-prefix=X-Remote-Extra-

this request:

GET / HTTP/1.1
X-Remote-User: fido
X-Remote-Group: dogs
X-Remote-Group: dachshunds
X-Remote-Extra-Acme.com%2Fproject: some-project
X-Remote-Extra-Scopes: openid
X-Remote-Extra-Scopes: profile

would result in this user info:

name: fido
groups:
- dogs
- dachshunds
extra:
  acme.com/project:
  - some-project
  scopes:
  - openid
  - profile

Client certificate

In order to prevent header spoofing, the authenticating proxy is required to present a valid client certificate to the API server for validation against the specified CA before the request headers are checked.

Do not reuse a CA that is used in a different context unless you understand the risks and the mechanisms to protect the CA's usage.

User impersonation

A user can act as another user through impersonation headers. These let requests manually override the user info a request authenticates as. For example, an admin could use this feature to debug an authorization policy by temporarily impersonating another user and seeing if a request was denied.

Impersonation requests first authenticate as the requesting user, then switch to the impersonated user info.

• A user makes an API call with their credentials and impersonation headers.
• API server authenticates the user.
• API server ensures the authenticated users have impersonation privileges.
• Request user info is replaced with impersonation values.
• Request is evaluated, authorization acts on impersonated user info.

The following HTTP headers can be used to performing an impersonation request:

• Impersonate-User: The username to act as.
• Impersonate-Group: A group name to act as. Can be provided multiple times to set multiple groups. Optional. Requires "Impersonate-User".
• Impersonate-Extra-( extra name ): A dynamic header used to associate extra fields with the user. Optional. Requires "Impersonate-User". In order to be preserved consistently, ( extra name ) must be lower-case, and any characters which aren't legal in HTTP header labels MUST be utf8 and percent-encoded.
• Impersonate-Uid: A unique identifier that represents the user being impersonated. Optional. Requires "Impersonate-User". Kubernetes does not impose any format requirements on this string.

An example of the impersonation headers used when impersonating a user with groups:

Impersonate-User: jane.doe@example.com
Impersonate-Group: developers
Impersonate-Group: admins

An example of the impersonation headers used when impersonating a user with a UID and extra fields:

Impersonate-User: jane.doe@example.com
Impersonate-Extra-dn: cn=jane,ou=engineers,dc=example,dc=com
Impersonate-Extra-acme.com%2Fproject: some-project
Impersonate-Extra-scopes: view
Impersonate-Extra-scopes: development
Impersonate-Uid: 06f6ce97-e2c5-4ab8-7ba5-7654dd08d52b

When using kubectl set the --as command line argument to configure the Impersonate-User header, you can also set the --as-group flag to configure the Impersonate-Group header.

kubectl drain mynode

Error from server (Forbidden): User "clark" cannot get nodes at the cluster scope. (get nodes mynode)

Set the --as and --as-group flag:

kubectl drain mynode --as=superman --as-group=system:masters

node/mynode cordoned
node/mynode drained

To impersonate a user, group, user identifier (UID) or extra fields, the impersonating user must have the ability to perform the impersonate verb on the kind of attribute being impersonated ("user", "group", "uid", etc.). For clusters that enable the RBAC authorization plugin, the following ClusterRole encompasses the rules needed to set user and group impersonation headers:

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: impersonator
rules:
- apiGroups: [""]
  resources: ["users", "groups", "serviceaccounts"]
  verbs: ["impersonate"]

For impersonation, extra fields and impersonated UIDs are both under the "authentication.k8s.io" apiGroup. Extra fields are evaluated as sub-resources of the resource "userextras". To allow a user to use impersonation headers for the extra field scopes and for UIDs, a user should be granted the following role:

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: scopes-and-uid-impersonator
rules:
# Can set "Impersonate-Extra-scopes" header and the "Impersonate-Uid" header.
- apiGroups: ["authentication.k8s.io"]
  resources: ["userextras/scopes", "uids"]
  verbs: ["impersonate"]

The values of impersonation headers can also be restricted by limiting the set of resourceNames a resource can take.

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: limited-impersonator
rules:
# Can impersonate the user "jane.doe@example.com"
- apiGroups: [""]
  resources: ["users"]
  verbs: ["impersonate"]
  resourceNames: ["jane.doe@example.com"]

# Can impersonate the groups "developers" and "admins"
- apiGroups: [""]
  resources: ["groups"]
  verbs: ["impersonate"]
  resourceNames: ["developers","admins"]

# Can impersonate the extras field "scopes" with the values "view" and "development"
- apiGroups: ["authentication.k8s.io"]
  resources: ["userextras/scopes"]
  verbs: ["impersonate"]
  resourceNames: ["view", "development"]

# Can impersonate the uid "06f6ce97-e2c5-4ab8-7ba5-7654dd08d52b"
- apiGroups: ["authentication.k8s.io"]
  resources: ["uids"]
  verbs: ["impersonate"]
  resourceNames: ["06f6ce97-e2c5-4ab8-7ba5-7654dd08d52b"]

client-go credential plugins

k8s.io/client-go and tools using it such as kubectl and kubelet are able to execute an external command to receive user credentials.

This feature is intended for client side integrations with authentication protocols not natively supported by k8s.io/client-go (LDAP, Kerberos, OAuth2, SAML, etc.). The plugin implements the protocol specific logic, then returns opaque credentials to use. Almost all credential plugin use cases require a server side component with support for the webhook token authenticator to interpret the credential format produced by the client plugin.

Example use case

In a hypothetical use case, an organization would run an external service that exchanges LDAP credentials for user specific, signed tokens. The service would also be capable of responding to webhook token authenticator requests to validate the tokens. Users would be required to install a credential plugin on their workstation.

To authenticate against the API:

• The user issues a kubectl command.
• Credential plugin prompts the user for LDAP credentials, exchanges credentials with external service for a token.
• Credential plugin returns token to client-go, which uses it as a bearer token against the API server.
• API server uses the webhook token authenticator to submit a TokenReview to the external service.
• External service verifies the signature on the token and returns the user's username and groups.

Configuration

Credential plugins are configured through kubectl config files as part of the user fields.

• client.authentication.k8s.io/v1
• client.authentication.k8s.io/v1beta1

apiVersion: v1
kind: Config
users:
- name: my-user
  user:
    exec:
      # Command to execute. Required.
      command: "example-client-go-exec-plugin"

      # API version to use when decoding the ExecCredentials resource. Required.
      #
      # The API version returned by the plugin MUST match the version listed here.
      #
      # To integrate with tools that support multiple versions (such as client.authentication.k8s.io/v1beta1),
      # set an environment variable, pass an argument to the tool that indicates which version the exec plugin expects,
      # or read the version from the ExecCredential object in the KUBERNETES_EXEC_INFO environment variable.
      apiVersion: "client.authentication.k8s.io/v1"

      # Environment variables to set when executing the plugin. Optional.
      env:
      - name: "FOO"
        value: "bar"

      # Arguments to pass when executing the plugin. Optional.
      args:
      - "arg1"
      - "arg2"

      # Text shown to the user when the executable doesn't seem to be present. Optional.
      installHint: |
        example-client-go-exec-plugin is required to authenticate
        to the current cluster.  It can be installed:

        On macOS: brew install example-client-go-exec-plugin

        On Ubuntu: apt-get install example-client-go-exec-plugin

        On Fedora: dnf install example-client-go-exec-plugin

        ...

      # Whether or not to provide cluster information, which could potentially contain
      # very large CA data, to this exec plugin as a part of the KUBERNETES_EXEC_INFO
      # environment variable.
      provideClusterInfo: true

      # The contract between the exec plugin and the standard input I/O stream. If the
      # contract cannot be satisfied, this plugin will not be run and an error will be
      # returned. Valid values are "Never" (this exec plugin never uses standard input),
      # "IfAvailable" (this exec plugin wants to use standard input if it is available),
      # or "Always" (this exec plugin requires standard input to function). Required.
      interactiveMode: Never
clusters:
- name: my-cluster
  cluster:
    server: "https://172.17.4.100:6443"
    certificate-authority: "/etc/kubernetes/ca.pem"
    extensions:
    - name: client.authentication.k8s.io/exec # reserved extension name for per cluster exec config
      extension:
        arbitrary: config
        this: can be provided via the KUBERNETES_EXEC_INFO environment variable upon setting provideClusterInfo
        you: ["can", "put", "anything", "here"]
contexts:
- name: my-cluster
  context:
    cluster: my-cluster
    user: my-user
current-context: my-cluster

apiVersion: v1
kind: Config
users:
- name: my-user
  user:
    exec:
      # Command to execute. Required.
      command: "example-client-go-exec-plugin"

      # API version to use when decoding the ExecCredentials resource. Required.
      #
      # The API version returned by the plugin MUST match the version listed here.
      #
      # To integrate with tools that support multiple versions (such as client.authentication.k8s.io/v1),
      # set an environment variable, pass an argument to the tool that indicates which version the exec plugin expects,
      # or read the version from the ExecCredential object in the KUBERNETES_EXEC_INFO environment variable.
      apiVersion: "client.authentication.k8s.io/v1beta1"

      # Environment variables to set when executing the plugin. Optional.
      env:
      - name: "FOO"
        value: "bar"

      # Arguments to pass when executing the plugin. Optional.
      args:
      - "arg1"
      - "arg2"

      # Text shown to the user when the executable doesn't seem to be present. Optional.
      installHint: |
        example-client-go-exec-plugin is required to authenticate
        to the current cluster.  It can be installed:

        On macOS: brew install example-client-go-exec-plugin

        On Ubuntu: apt-get install example-client-go-exec-plugin

        On Fedora: dnf install example-client-go-exec-plugin

        ...

      # Whether or not to provide cluster information, which could potentially contain
      # very large CA data, to this exec plugin as a part of the KUBERNETES_EXEC_INFO
      # environment variable.
      provideClusterInfo: true

      # The contract between the exec plugin and the standard input I/O stream. If the
      # contract cannot be satisfied, this plugin will not be run and an error will be
      # returned. Valid values are "Never" (this exec plugin never uses standard input),
      # "IfAvailable" (this exec plugin wants to use standard input if it is available),
      # or "Always" (this exec plugin requires standard input to function). Optional.
      # Defaults to "IfAvailable".
      interactiveMode: Never
clusters:
- name: my-cluster
  cluster:
    server: "https://172.17.4.100:6443"
    certificate-authority: "/etc/kubernetes/ca.pem"
    extensions:
    - name: client.authentication.k8s.io/exec # reserved extension name for per cluster exec config
      extension:
        arbitrary: config
        this: can be provided via the KUBERNETES_EXEC_INFO environment variable upon setting provideClusterInfo
        you: ["can", "put", "anything", "here"]
contexts:
- name: my-cluster
  context:
    cluster: my-cluster
    user: my-user
current-context: my-cluster

Relative command paths are interpreted as relative to the directory of the config file. If KUBECONFIG is set to /home/jane/kubeconfig and the exec command is ./bin/example-client-go-exec-plugin, the binary /home/jane/bin/example-client-go-exec-plugin is executed.

- name: my-user
  user:
    exec:
      # Path relative to the directory of the kubeconfig
      command: "./bin/example-client-go-exec-plugin"
      apiVersion: "client.authentication.k8s.io/v1"
      interactiveMode: Never

Input and output formats

The executed command prints an ExecCredential object to stdout. k8s.io/client-go authenticates against the Kubernetes API using the returned credentials in the status. The executed command is passed an ExecCredential object as input via the KUBERNETES_EXEC_INFO environment variable. This input contains helpful information like the expected API version of the returned ExecCredential object and whether or not the plugin can use stdin to interact with the user.

When run from an interactive session (i.e., a terminal), stdin can be exposed directly to the plugin. Plugins should use the spec.interactive field of the input ExecCredential object from the KUBERNETES_EXEC_INFO environment variable in order to determine if stdin has been provided. A plugin's stdin requirements (i.e., whether stdin is optional, strictly required, or never used in order for the plugin to run successfully) is declared via the user.exec.interactiveMode field in the kubeconfig (see table below for valid values). The user.exec.interactiveMode field is optional in client.authentication.k8s.io/v1beta1 and required in client.authentication.k8s.io/v1.

To use bearer token credentials, the plugin returns a token in the status of the ExecCredential

• client.authentication.k8s.io/v1
• client.authentication.k8s.io/v1beta1

{
  "apiVersion": "client.authentication.k8s.io/v1",
  "kind": "ExecCredential",
  "status": {
    "token": "my-bearer-token"
  }
}

{
  "apiVersion": "client.authentication.k8s.io/v1beta1",
  "kind": "ExecCredential",
  "status": {
    "token": "my-bearer-token"
  }
}

Alternatively, a PEM-encoded client certificate and key can be returned to use TLS client auth. If the plugin returns a different certificate and key on a subsequent call, k8s.io/client-go will close existing connections with the server to force a new TLS handshake.

If specified, clientKeyData and clientCertificateData must both must be present.

clientCertificateData may contain additional intermediate certificates to send to the server.

• client.authentication.k8s.io/v1
• client.authentication.k8s.io/v1beta1

{
  "apiVersion": "client.authentication.k8s.io/v1",
  "kind": "ExecCredential",
  "status": {
    "clientCertificateData": "-----BEGIN CERTIFICATE-----\n...\n-----END CERTIFICATE-----",
    "clientKeyData": "-----BEGIN RSA PRIVATE KEY-----\n...\n-----END RSA PRIVATE KEY-----"
  }
}

{
  "apiVersion": "client.authentication.k8s.io/v1beta1",
  "kind": "ExecCredential",
  "status": {
    "clientCertificateData": "-----BEGIN CERTIFICATE-----\n...\n-----END CERTIFICATE-----",
    "clientKeyData": "-----BEGIN RSA PRIVATE KEY-----\n...\n-----END RSA PRIVATE KEY-----"
  }
}

Optionally, the response can include the expiry of the credential formatted as a RFC 3339 timestamp.

Presence or absence of an expiry has the following impact:

• If an expiry is included, the bearer token and TLS credentials are cached until the expiry time is reached, or if the server responds with a 401 HTTP status code, or when the process exits.
• If an expiry is omitted, the bearer token and TLS credentials are cached until the server responds with a 401 HTTP status code or until the process exits.

• client.authentication.k8s.io/v1
• client.authentication.k8s.io/v1beta1

{
  "apiVersion": "client.authentication.k8s.io/v1",
  "kind": "ExecCredential",
  "status": {
    "token": "my-bearer-token",
    "expirationTimestamp": "2018-03-05T17:30:20-08:00"
  }
}

{
  "apiVersion": "client.authentication.k8s.io/v1beta1",
  "kind": "ExecCredential",
  "status": {
    "token": "my-bearer-token",
    "expirationTimestamp": "2018-03-05T17:30:20-08:00"
  }
}

To enable the exec plugin to obtain cluster-specific information, set provideClusterInfo on the user.exec field in the kubeconfig. The plugin will then be supplied this cluster-specific information in the KUBERNETES_EXEC_INFO environment variable. Information from this environment variable can be used to perform cluster-specific credential acquisition logic. The following ExecCredential manifest describes a cluster information sample.

• client.authentication.k8s.io/v1
• client.authentication.k8s.io/v1beta1

{
  "apiVersion": "client.authentication.k8s.io/v1",
  "kind": "ExecCredential",
  "spec": {
    "cluster": {
      "server": "https://172.17.4.100:6443",
      "certificate-authority-data": "LS0t...",
      "config": {
        "arbitrary": "config",
        "this": "can be provided via the KUBERNETES_EXEC_INFO environment variable upon setting provideClusterInfo",
        "you": ["can", "put", "anything", "here"]
      }
    },
    "interactive": true
  }
}

{
  "apiVersion": "client.authentication.k8s.io/v1beta1",
  "kind": "ExecCredential",
  "spec": {
    "cluster": {
      "server": "https://172.17.4.100:6443",
      "certificate-authority-data": "LS0t...",
      "config": {
        "arbitrary": "config",
        "this": "can be provided via the KUBERNETES_EXEC_INFO environment variable upon setting provideClusterInfo",
        "you": ["can", "put", "anything", "here"]
      }
    },
    "interactive": true
  }
}

API access to authentication information for a client

If your cluster has the API enabled, you can use the SelfSubjectReview API to find out how your Kubernetes cluster maps your authentication information to identify you as a client. This works whether you are authenticating as a user (typically representing a real person) or as a ServiceAccount.

In a typical Kubernetes cluster, all authenticated users can create SelfSubjectReview objects. Access to do this is allowed by the built-in system:basic-user ClusterRole.

SelfSubjectReview objects do not have any configurable fields. On receiving a request, the Kubernetes API server fills the status with the user attributes and returns it to the user.

Request example (the body would be a SelfSubjectReview):

POST /apis/authentication.k8s.io/v1/selfsubjectreviews

{
  "apiVersion": "authentication.k8s.io/v1",
  "kind": "SelfSubjectReview"
}

Response example:

{
  "apiVersion": "authentication.k8s.io/v1",
  "kind": "SelfSubjectReview",
  "status": {
    "userInfo": {
      "name": "jane.doe",
      "groups": [
        "viewers",
        "editors",
        "system:authenticated"
      ],
      "extra": {
        "provider_id": ["token.company.example"]
      }
    }
  }
}

This example response does not include a uid field; not all authentication mechanisms make a uid available to the API server.

Using the Accept: HTTP header, you can request a response in either JSON or YAML; for example:

• JSON
• YAML

{
  "apiVersion": "authentication.k8s.io/v1",
  "kind": "SelfSubjectReview",
  "status": {
    "userInfo": {
      "username": "jane.doe",
      "uid": "b79dbf30-0c6a-11ed-861d-0242ac120002",
      "groups": [
        "students",
        "teachers",
        "system:authenticated"
      ],
      "extra": {
        "skills": [
          "reading",
          "learning"
        ],
        "subjects": [
          "math",
          "sports"
        ]
      }
    }
  }
}

apiVersion: authentication.k8s.io/v1
kind: SelfSubjectReview
status:
  userInfo:
    username: jane.doe
    uid: b79dbf30-0c6a-11ed-861d-0242ac120002
    groups:
    - students
    - teachers
    - system:authenticated
    extra:
      skills:
      - reading
      - learning
      subjects:
      - math
      - sports

For convenience, the kubectl auth whoami subcommand is available. See kubectl auth whoami for more details.

The ability for a client to learn its own identity is extremely useful when troubleshooting a complicated authentication flow that is used in a Kubernetes cluster; for example, if you use webhook token authentication or an authenticating proxy.

What's next

• Read about authorization in Kubernetes
• To learn about issuing certificates for users, read Issue a Certificate for a Kubernetes API Client Using A CertificateSigningRequest
• Read the client authentication reference (v1)
• Read the client authentication reference (v1beta1)
